MICHELIN XZM 2+A
Discover a versatile option for your port vehicles. Its enhanced robustness optimizes productivity and effectively extends service life.
Why choose the MICHELIN XZM 2+A tyre?
Treadlife
Robustness
Productivity
MICHELIN XZM 2+A Technology
Tyre Technical Specifications
Technical Specifications
| Product | MICHELIN XZM2+A - 18.00R25 |
|---|---|
| Overall Diameter | 66 inch |
| Section width | 20 inch |
| Approved rims | 15.00/2.5 |
| Recommended rims | 13.00/2.5 |
| Rolling circumference (mm) | 5032 |
| Filling volume 100% (lts) | 470 l |
| Load Index | 207 |
| Speed Index | A5 |
| Tread depth | 3.1 inch |
| TRA code | IND-5 |
| Min Dual Spacing | 24.09 inch |
| CAI | 578448 |
Load & Pressure
|
psi |
87 |
116 |
145 |
|---|---|---|---|
| (kg - lbs) counterbalanced-lift-truck-steer-wheel | |||
|
0 km/h 0 mph |
18380 40521 |
22280 49119 |
26250 57871 |
|
25 km/h 16 mph |
12250 27007 |
14750 32518 |
17500 38581 |
| (kg - lbs) counterbalanced-lift-truck-load-wheel | |||
|
10 km/h 6 mph |
15930 35120 |
19180 42285 |
22750 50155 |
|
25 km/h 16 mph |
15930 35120 |
19180 42285 |
22750 50155 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tyre, the speed of travel and the work to be done. Our recommendations above are provided subject to changes made after the date of publication of these tables (December 2020). Technical data is subject to change without prior notice.
Technical Specifications
| Product | MICHELIN XZM2+A - 18.00R25 |
|---|---|
| Overall Diameter | 66 inch |
| Section width | 20 inch |
| Approved rims | 15.00/2.5 |
| Recommended rims | 13.00/2.5 |
| Rolling circumference (mm) | 5032 |
| Filling volume 100% (lts) | 470 l |
| Load Index | 207 |
| Speed Index | A5 |
| Tread depth | 3.1 inch |
| TRA code | IND-5 |
| Min Dual Spacing | 24.09 inch |
| CAI | 578448 |
Load & Pressure
|
psi |
87 |
116 |
145 |
|---|---|---|---|
| (kg - lbs) counterbalanced-lift-truck-steer-wheel | |||
|
0 km/h 0 mph |
18380 40521 |
22280 49119 |
26250 57871 |
|
25 km/h 16 mph |
12250 27007 |
14750 32518 |
17500 38581 |
| (kg - lbs) counterbalanced-lift-truck-load-wheel | |||
|
10 km/h 6 mph |
15930 35120 |
19180 42285 |
22750 50155 |
|
25 km/h 16 mph |
15930 35120 |
19180 42285 |
22750 50155 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tyre, the speed of travel and the work to be done. Our recommendations above are provided subject to changes made after the date of publication of these tables (December 2020). Technical data is subject to change without prior notice.
Tyre Product Sheet and Databook
Find the technical and commercial specifications downloadable documents below.
(1) Compared with the same sized Michelin XZM tyre under normal use.
(2) Characteristic of the product measured with the TKPH indicator. Distance per hour is directly correlated to the amount of tons transportable in an hour.
