MICHELIN XLD D2A
Increase your productivity with outstanding tyre wear and the best grip and protection for your differents machines applications.
Why choose the MICHELIN XLD D2A tyre?
Traction
Robustness
Treadlife
MICHELIN XLD D2A Technology
Tyre Technical Specifications
Technical Specifications
| Product | MICHELIN XLD D2A - 29.5R29 |
|---|---|
| Overall Diameter | 79 inch |
| Section width | 30 inch |
| Approved rims | 24.00/3.5 |
| Recommended rims | 25.00/3.5 |
| Rolling circumference (mm) | 234 inch |
| Filling volume 100% (lts) | 985 l |
| Tread depth | 3.7 inch |
| TRA code | L-5 |
| CAI | 123279 |
Load & Pressure
|
psi |
29 |
36 |
44 |
51 |
58 |
65 |
73 |
76 |
80 |
|---|---|---|---|---|---|---|---|---|---|
| (kg - lbs) grader | |||||||||
|
all-axles |
7100 15653 |
8500 18739 |
9750 21495 |
10900 24030 |
12150 26786 |
13200 29101 |
14500 31967 |
15000 33069 |
|
| (kg - lbs) loader | |||||||||
|
front-laden |
13100 28881 |
14700 32408 |
16300 35935 |
17900 39463 |
19500 42990 |
21550 47510 |
23600 52029 |
24450 53903 |
25200 55556 |
|
rear-unladen |
10500 23149 |
11750 25904 |
13050 28770 |
14350 31636 |
15600 34392 |
17250 38030 |
18900 41667 |
10560 23281 |
21150 46628 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tyre, the speed of travel and the work to be done. Our recommendations above are provided subject to changes made after the date of publication of these tables (December 2020). Technical data is subject to change without prior notice.
Technical Specifications
| Product | MICHELIN XLD D2A - 29.5R29 |
|---|---|
| Overall Diameter | 79 inch |
| Section width | 30 inch |
| Approved rims | 24.00/3.5 |
| Recommended rims | 25.00/3.5 |
| Rolling circumference (mm) | 234 inch |
| Filling volume 100% (lts) | 985 l |
| Tread depth | 3.7 inch |
| TRA code | L-5 |
| CAI | 123279 |
Load & Pressure
|
psi |
29 |
36 |
44 |
51 |
58 |
65 |
73 |
76 |
80 |
|---|---|---|---|---|---|---|---|---|---|
| (kg - lbs) grader | |||||||||
|
all-axles |
7100 15653 |
8500 18739 |
9750 21495 |
10900 24030 |
12150 26786 |
13200 29101 |
14500 31967 |
15000 33069 |
|
| (kg - lbs) loader | |||||||||
|
front-laden |
13100 28881 |
14700 32408 |
16300 35935 |
17900 39463 |
19500 42990 |
21550 47510 |
23600 52029 |
24450 53903 |
25200 55556 |
|
rear-unladen |
10500 23149 |
11750 25904 |
13050 28770 |
14350 31636 |
15600 34392 |
17250 38030 |
18900 41667 |
10560 23281 |
21150 46628 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tyre, the speed of travel and the work to be done. Our recommendations above are provided subject to changes made after the date of publication of these tables (December 2020). Technical data is subject to change without prior notice.
Tyre Product Sheet and Databook
Find the technical and commercial specifications downloadable documents below.
