MICHELIN XZR
The solution for baggage tractors, urban machines and other specific high intensity forklift uses with an exceptional total value of ownership.
Why choose the MICHELIN XZR tyre?
Speed
Safety
Robustness
MICHELIN XZR Technology
Tyre Technical Specifications
Technical Specifications
| Product | MICHELIN XZR - 6.00R9 |
|---|---|
| Overall Diameter | 21 inch |
| Section width | 6 inch |
| Recommended rims | 4.00E |
| Rolling circumference (mm) | 1605 |
| Filling volume 100% (lts) | 18 l |
| Load Index | 121 |
| Speed Index | A5 |
| Tread depth | 0.4 inch |
| TRA code | IND-3 |
| Min Dual Spacing | 7.56 inch |
| CAI | 110206 |
Load & Pressure
|
psi |
87 |
116 |
145 |
|---|---|---|---|
| (kg - lbs) counterbalanced-lift-truck-steer-wheel | |||
|
0 km/h 0 mph |
1590 3505 |
1890 4167 |
2190 4828 |
|
25 km/h 16 mph |
1050 2315 |
1250 2756 |
1450 3197 |
|
35 km/h 22 mph |
980 2161 |
1160 2557 |
1350 2976 |
|
40 km/h 25 mph |
940 2072 |
1120 2469 |
1300 2866 |
|
50 km/h 31 mph |
890 1962 |
1050 2315 |
1220 2690 |
| (kg - lbs) counterbalanced-lift-truck-load-wheel | |||
|
10 km/h 6 mph |
1370 3020 |
1630 3594 |
1890 4167 |
|
25 km/h 16 mph |
1370 3020 |
1630 3594 |
1890 4167 |
|
35 km/h 22 mph |
1320 2910 |
1570 3461 |
1820 4012 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tyre, the speed of travel and the work to be done. Our recommendations above are provided subject to changes made after the date of publication of these tables (December 2020). Technical data is subject to change without prior notice.
Technical Specifications
| Product | MICHELIN XZR - 6.00R9 |
|---|---|
| Overall Diameter | 21 inch |
| Section width | 6 inch |
| Recommended rims | 4.00E |
| Rolling circumference (mm) | 1605 |
| Filling volume 100% (lts) | 18 l |
| Load Index | 121 |
| Speed Index | A5 |
| Tread depth | 0.4 inch |
| TRA code | IND-3 |
| Min Dual Spacing | 7.56 inch |
| CAI | 110206 |
Load & Pressure
|
psi |
87 |
116 |
145 |
|---|---|---|---|
| (kg - lbs) counterbalanced-lift-truck-steer-wheel | |||
|
0 km/h 0 mph |
1590 3505 |
1890 4167 |
2190 4828 |
|
25 km/h 16 mph |
1050 2315 |
1250 2756 |
1450 3197 |
|
35 km/h 22 mph |
980 2161 |
1160 2557 |
1350 2976 |
|
40 km/h 25 mph |
940 2072 |
1120 2469 |
1300 2866 |
|
50 km/h 31 mph |
890 1962 |
1050 2315 |
1220 2690 |
| (kg - lbs) counterbalanced-lift-truck-load-wheel | |||
|
10 km/h 6 mph |
1370 3020 |
1630 3594 |
1890 4167 |
|
25 km/h 16 mph |
1370 3020 |
1630 3594 |
1890 4167 |
|
35 km/h 22 mph |
1320 2910 |
1570 3461 |
1820 4012 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tyre, the speed of travel and the work to be done. Our recommendations above are provided subject to changes made after the date of publication of these tables (December 2020). Technical data is subject to change without prior notice.
Tyre Product Sheet and Databook
Find the technical and commercial specifications downloadable documents below.
(1) Characteristic of the product measured with the TKPH indicator.
